Name
Split Wide Quads (QuadSplit) — Split quadrilaterals with large interior angles.
Synopsis
QuadSplit(angle)
Details
-
Base class:
Rationalizer -
Parameters:
angle- Maximum acceptable interior angle Type: A real number in the range [90, 180].
Description
QuadSplit is a Rationalizer applied by the Rationalize Skeleton modifier. As
shown in Figure 6.94 it splits quadrilateral
Elements into two triangular Elements, if the quadrilateral has an
interior angle greater than angle. Unlike other
rationalizers, QuadSplit doesn't affect its
neighboring elements.
Figure 6.94. Applying QuadSplit
The highlighted quadrilateral Element in (a) is split into two
triangles in (b).
|
|
 |
|
