`Point boundary from elements (PointFromElements)`
	6.5.2. Subclasses

Name

Point boundary from elements (PointFromElements) — Construct a point boundary surrounding a set of elements.

PointFromElements(group)

Base class: BoundaryConstructor
Parameters:

group

Construct the boundary from these elements Type: The name of a element group, or the placeholder selection, referring to the currently selected elements.

PointFromElements is a BoundaryConstructor, used as the constructor argument of the OOF.Skeleton.Boundary.Construct command when building Skeleton boundaries. It creates Point Boundaries from the currently selected Skeleton Elements or from a group of Elements. The Elements are specified by the group parameter, which must be either the name of a Element group or the special placeholder object, selection.

Like when constructing an edge boundary from Elements, and unlike when constructing a point boundary from Segments, only the points on the exterior of the Element set are included in the boundary.

Figure 6.92. Constructing a Point Boundary from Elements

(a) A Skeleton with some selected Elements (in dark red).

(b) The point boundary (orange dots) constructed from the selected Elements. Only the Nodes on the exterior of the Element set are included.
