OOF2: The Manual
Spectral (SpectralMap) |
||
|---|---|---|
|
6.5.2. Subclasses |  |
Name
Spectral (SpectralMap) — blue, green, yellow, orange, red
Synopsis
SpectralMap(saturation, value)
Details
-
Base class:
ColorMap -
Parameters:
saturation- 0.0=weak, 1.0=strong Type: A real number in the range [0, 1].
value- 0.0=dark, 1.0=light Type: A real number in the range [0, 1].
Description
ColorMaps
translate numbers into colors, for use in contour plots.
SpectralMap maps colors in spectral order
(blue-green-yellow-orange-red, from low to high values).
The saturation and value
parameters determine the fixed saturation and value of all the colors in
the map.
Figure 6.111. The Spectral Color Map
Three versions of the spectral color map with different parameters. High values are on top.
(a) The default values, saturation=1 and
value=1.0.
(b) saturation=0.5 and value=1.0.
(c) saturation=1.0 and value=0.5.
|
|
 |
|
