OOF2 version 2.2.3 is
The major difference between 2.2.x and 2.1 is that 2.2 uses
a newer graphics library for its user interface. There are
other significant improvements. See
the change log for details.
differences between 2.1 and 2.0 are that 2.1 can solve
time dependent problems, and has much improved
nonlinear solvers. A detailed discussion of the
differences and a summary of how to use the new
features is included in
the What's New in 2.1
OOF2 version 2.1.19 can now be run on
for more details.
OOF2 retains (almost) all of the features of OOF1,
although it does not read OOF1 data files. The latest
versions of OOF1, however, can write OOF2 data files.
OOF2 is a set of C++ classes for finite elements and
material properties, tied together in a Python
is an easy to use, high-level, object-oriented
OOF2 is in
Here is a brief list of OOF2 features:
OOF2 can potentially handle any problem of the form:
- "Flux = Modulus times gradient of Field"
Currently OOF2 can solve the heat equation, mechanical force
balance, and the Coulomb equation. It includes material
properties for linear elasticity, body forces (gravity),
thermal conductivity, heat sources, dielectric permittivity,
space charge (in an approximation in which charges interact
only with the local polarization field, not with other charges
at a distance), thermal expansion, and piezoelectricity.
- "divergence of Flux = Applied Force".
New Fields and Fluxes can be added with only a few lines of
Python code. New material properties can be added with a few
lines of Python code, or, if speed is an issue, in C++.
(Defining new Properties is not quite as simple as defining
new Fields.) Instructions for adding features to OOF2 are
given in the manual.
Materials are built from a collection of Properties. Any
combination of Properties is allowed, with reasonable
constraints on completeness and unambiguity.
OOF2 contains a small variety of finite elements and new ones
can be added easily in C++. OOF2 has 3 noded triangles, 4
noded quadrilaterals, 6 noded subparametric triangles, and 8
noded subparametric quadrilaterals.
OOF2 generates and refines triangular,
quadrilateral, and mixed meshes from image data.
Element order is specified independently from
OOF2 incorporates nonlinear solvers. (But not many
non-linear material properties are yet present.)
OOF2 can refine meshes adaptively using a-posteriori
OOF2 is threaded, meaning that it can perform
multiple calculations simultaneously.
OOF2 is not yet fully parallel -- many operations that could
be done in parallel are not.
OOF2 is completely scriptable in Python, and can
also be run interactively from a graphical user
OOF2 has flexible graphical output.
OOF2 can export mesh geometry directly into
OOF2 can read EBSD
orientation map data files. See the
OOF2 Orientation Mapping
page for more information.
OOF2 can solve time dependent problems.
OOF2 can solve problems in
which the flux cannot be written as modulus times
We're working on including the following features in OOF2:
Expanding the scope of the problems solved.
Non-linear physics, including plasticity and large strain.
Line elements, as well as elements with higher order
continuity (for phase-field or strain-gradient
OOF2 is the basis for OOF3D, which solves 3
dimensional problems. OOF2 and OOF3D are separate programs,
but are more or less evolving together.
OOF2 will run on any computer running a relatively recent
variant of the Unix operating system, including Linux and
Macintosh, as long as the prerequisites listed below are
scripting language, version 2.7. OOF2 might work with
earlier versions, but it hasn't been tested there. OOF2
does not (yet) work with Python 3.
The OOFCanvas library, version
1.0.3 or later.
Magick++ image processing library, version 6.x. OOF2
does not work with ImageMagick 7.
graphics toolkit. OOF2 requires version
3.22 or later, but not as late as version 4.0.
The Python bindings for
version 3.26 or later.
basic linear algebra subroutines and the lapack
linear algebra library. These are provided with
many computer systems.
In addition, if you are going to be compiling OOF2, you
a C++ compiler.
The yacc and make utilities.
Detailed instructions for installing the prerequisites
on various operating systems may be
Disclaimer and Copyright
The research software provided on this web site
("software") is provided by NIST as a public
service. You may use, copy and distribute copies of
the software in any medium, provided that you keep
intact this entire notice. You may improve, modify and
create derivative works of the software or any portion
of the software, and you may copy and distribute such
modifications or works. Modified works should carry a
notice stating that you changed the software and
should note the date and nature of any such
change. Please explicitly acknowledge the National
Institute of Standards and Technology as the source of
the software. To facilitate maintenance we ask that
before distributing modified versions of this
software, you first contact the authors at
The software is expressly provided "AS IS". NIST MAKES
NO WARRANTY OF ANY KIND, EXPRESS, IMPLIED, IN FACT OR
ARISING BY OPERATION OF LAW, INCLUDING, WITHOUT
LIMITATION, THE IMPLIED WARRANTY OF MERCHANTABILITY,
FITNESS FOR A PARTICULAR PURPOSE, NON-INFRINGEMENT AND
DATA ACCURACY. NIST NEITHER REPRESENTS NOR WARRANTS
THAT THE OPERATION OF THE SOFTWARE WILL BE
UNINTERRUPTED OR ERROR-FREE, OR THAT ANY DEFECTS WILL
BE CORRECTED. NIST DOES NOT WARRANT OR MAKE ANY
REPRESENTATIONS REGARDING THE USE OF THE SOFTWARE OR
THE RESULTS THEREOF, INCLUDING BUT NOT LIMITED TO THE
CORRECTNESS, ACCURACY, RELIABILITY, OR USEFULNESS OF
You are solely responsible for determining the
appropriateness of using and distributing the software
and you assume all risks associated with its use,
including but not limited to the risks and costs of
program errors, compliance with applicable laws,
damage to or loss of data, programs or equipment, and
the unavailability or interruption of operation. This
software is not intended to be used in any situation
where a failure could cause risk of injury or damage
to property. The software was developed by NIST
employees. NIST employee contributions are not subject
to copyright protection within the United States.
Please read the Disclaimer and
Copyright notice before downloading this
Please read the Disclaimer and
Copyright notice before installing this
This is just a summary! Please see
the README file for the
OOF2 prerequisites. We
strongly recommend that you use a package management
system to do so.
The downloaded file is a compressed tar archive. If
your browser didn't unpack it for you, unpack it
% tar -xzf oof2-2.2.2.tar.gz
This will create a directory called "oof2-2.2.2".
cd to that directory.
Read the README.md
file and follow the directions in it.
Additional system-specific installation notes
are available here,
and some frequently asked questions are answered
in the FAQ.
The short instructions are to type this:
python setup.py build
sudo python setup.py install
to install in a system directory,
python setup.py install --prefix=$HOME
to install in your home directory. But please read
the README file. It's
important to ensure that you use Python 2.7 to build and
If you like, run the test suites located in the
TEST and TEST/GUI subdirectories of the OOF2
distribution. Read the README files in those
directories for instructions. As of version
2.2.0, shortcuts named "oof2-test" and
"oof2-guitest" are installed alongside OOF2 and
can be run by typing their names.
After installing OOF2, you should have an executable
file named oof2 in a bin directory in your
execution path. You can now simply type oof2
at your shell prompt, and OOF2 will start up.
OOF also has many options, and you can get a summary of
them by typing oof2 --help.
By default, OOF runs in graphics mode, opening a couple
of windows to get you started. If you don't want this,
you can use the --text option to run it in
Most importantly, explore the Tutorials in the
Help menu. (The tutorials are only available in
Getting Started with OOF2
2.1 explains the differences between 2.0.5 and
If you run into trouble, please check the
The OOF2 Manual is available
You can also download the html
files as a gzipped tar file (8926465 bytes).
Use tar -xzf oof2man.tgz to unpack it.
If you're familiar with OOF2 2.0,
the Getting Started with OOF2
2.1 page summarizes the differences between
versions 2.0 and 2.1.
Please check the FAQ before
submitting bug reports. Send bug reports via e-mail
Include the following information with your report:
The type of computer and operating system that
The version of OOF2 that you're using. Starting
OOF2 with the --version flag will print the
A complete description of the problem: what
happened, and what did you do to make it happen? Be
as specific and detailed as possible.
If possible, an OOF2 script that reproduces the
problem. A script can be saved from the
"File/Save/Python Log" menu item in the main OOF2
window, or the "Save" button in the "Quit" dialog
If OOF2 crashes before you get a chance to save a
script, a script will be saved automatically in
the directory that your operating system uses for
temporary files, which is probably /tmp.
Look for a file with oof2 in its name
in a subdirectory of /tmp.
Be sure to include any files that the script
